Serial number: YC-400TX4HGE
Weldable materials: carbon steel, stainless steel
Load duration: 60%
Input voltage: 3-phase 380V
Rated specifications
| Power supply model | YC-400TX4 | |
|---|---|---|
| Product Serial Number | YC-400TX4HGE | |
|
Rated input voltage |
AC three-phase 380 V |
|
|
Rated input capacity |
TIG |
13.5 kVA |
|
Electrode arc welding |
17.85 kVA |
|
|
Rated input power |
TIG |
12.8 kW |
|
Electrode arc welding |
17 kW |
|
|
Power factor |
0.95 |
|
|
Rated no-load voltage |
73 V |
|
|
Output current range |
TIG |
4－400 A |
|
Electrode arc welding |
20－400 A |
|
|
Output voltage range |
TIG |
10.2－26 V |
|
Electrode arc welding |
20.8－36 V |
|
|
Rated load duration |
60% |
|
|
Way to control |
Digital IGBT inverter control |
|
|
Pulse frequency adjustment range |
0.1－500 Hz |
|
| Insulation class | 130°C (reactor 180°C) | |
| Protection level | IP23 | |
| Dimensions (W×D×H) | 340*558*603 mm | |
| Weight | 44 kg | |
